Explore our export-grade automobile hardware portfolio. Every item is machined from aerospace-grade Ti-6Al-4V titanium alloy, offering 43% weight reduction over steel, lifetime rust immunity, and high-temperature integrity.
In high-torque automotive environments, using substandard titanium grades like commercial pure titanium (GR2) risks thread shearing and fatigue failure. Verqo Titanium Products Co., Ltd. strictly specifies aerospace-grade Ti-6Al-4V.
| Mechanical Property | Verqo GR5 (Ti-6Al-4V) | Automotive 10.9 Steel | SUS304 Stainless |
|---|---|---|---|
| Density (g/cm³) | 4.43 (43% Lighter) | 7.85 | 7.93 |
| Tensile Strength (MPa) | ≥ 895 – 1,020 | 1,040 | 520 – 700 |
| Yield Strength (MPa) | ≥ 828 | 940 | 205 – 240 |
| Corrosion Resistance | Impervious to Salt/Acids | Requires Plating | Susceptible to Pitting |
| Max Service Temp (°C) | Up to 450°C | Up to 300°C | Up to 300°C |
| Magnetic Permeability | Non-Magnetic (μ < 1.0001) | Ferromagnetic | Slightly Magnetic |
| Primary Automotive Use | Lug Nuts, Shift Knobs, Drain Plugs | Engine Core Bolts | Decorative Body Trim |
Values certified per ASTM B348 / ISO 3506 standards. Mill test reports (MTR) with heat number chemistry provided with every bulk commercial shipment.
Cutting unsprung weight on rotating assemblies like wheels, hubs, and valve stems directly improves suspension response, steering agility, and acceleration performance.
Titanium threads have high surface friction under high clamping loads. Always use an approved anti-seize paste (copper or molybdenum base) and reduce dry torque values by 15% to 20%.
Unlike steel fasteners that corrode or weld-seize when subjected to exhaust heat cycles, GR5 titanium maintains high creep resistance and releases cleanly without snapping.
With 10 years of export experience and an equipped 1,001–2,000 m² machining workshop in Baoji, we turn concept sketches, 2D prints, and 3D CAD files into race-ready components.
Our fleet of multi-axis CNC turning and Swiss lathes achieves tight dimensional tolerances down to ±0.01 mm, supporting complex contours, custom knurling patterns, and fine metric or imperial threads.
Surface finishing options include multi-color electrolytic anodizing (gold, purple, burnt blue, emerald), mirror polish buffing, and physical vapor deposition (PVD) titanium nitride coatings for maximum hardness.
We offer laser marking for company brand logos, part numbers, and torque specifications, accompanied by custom retail blister cards, sealed foam cases, and export-compliant barcoded boxing.
Key information for international procurement managers, aftermarket distributors, and professional racing teams.
GR5 (Ti-6Al-4V) titanium delivers an unmatched strength-to-weight ratio with tensile strength exceeding 895 MPa while being approximately 43% lighter than steel. It provides total immunity to road salt, chemical exposure, and moisture corrosion, making it optimal for unsprung weight reduction on wheel hardware, drivetrain components, and exhaust systems.
Yes. Verqo Titanium Products Co., Ltd. provides comprehensive OEM and ODM precision CNC machining. We support thread specifications from M2 to M26 with tight tolerances of ±0.01 mm, custom thread pitches (such as M10x1.25, M12x1.25, M12x1.5, M14x1.5), custom knurling, and laser-engraved logos.
We offer precision mechanical mirror polishing, electrolytic anodization (burnt blue, gold, purple, green, rose), and durable PVD vacuum coatings (gloss black, neo-chrome oil slick, matte graphite) engineered for high wear resistance in harsh automotive environments.
For in-stock automotive items, our MOQ is flexible starting from 10 to 50 pieces. Custom CNC batches usually start at 50 to 100 pieces. Prototype samples are completed in 7 to 10 days, with bulk production delivered reliably within 15 to 25 business days.
Send your CAD models, technical drawings, or quantity specifications. Our engineering team provides DFM feedback and official quotations within 2 hours.
